E-Bike Conversion Kit 36V 250W 28" Rear Motor Kit for Freewheel with 36V 18Ah Battery and Charger

1. Technical Description
1) 36V 250W brushless geared rear freewheel motor, suitable with 6/7/8/9 speed freewheel;
2) comes with 28" double wall rim and 12G silver spokes, fit for 28" bikes and some 700C bikes;
3) 36V 18Ah downtube battery, the range is about 60-65km, comes with 42V 3A charger;
4) the max speed of motor is 25km/h;
5) the max torque of motor is 40N.m;
6) compatible with V-brake and disc brake;
7) requested installation width between forks is 138mm;
8) 36V 15A JYT integrated controller, connected to motor, PAS sensor and 4into1 cable;
9) 36V C500 LCD display with backlight, 5 assist levels;
10) PAS sensor for left side of bottom bracket, double hall sensor, 12 signals output;
11) thumb throttle, the max speed of throttle is 6km/h;
12) mechanical brake levers;

2. Packing List
1 x rear freewheel motor with 28" rim
1 x downtube battery
1 x charger
1 x integrated controller
1 x LCD display
1 x PAS sensor
1 x thumb throttle
1 x 4into1 cable
2 x brake levers
1 x controller bag
1 x free tools

3. Additional Information
* The warranty of motor and battery is 18 months. Other parts in kit have warranty of 12 months.
* The shipping takes 2-4 working days in Germany. In other countries, the shipping takes 4-8 working days.
* The max speed of motor is 25km/h. It can be set on display, but the speed limit can't be canceled.
* The pedal sensor in kit doesn't fit for Hollowtech II and Octalink. You will need this pedal sensor: https://yosepower.com/products/hollowtech-ii-sensor
* The brake levers in kit are not suitable for hydraulic brake. You will need these brake sensors: https://yosepower.com/products/hydraulic-brake-sensor
* These batteries can be bought separately as replacement:
36V13Ah/14.5Ah: https://yosepower.com/products/36v-13ah-14-5ah-down-tube-battery
36V18Ah: https://yosepower.com/products/36v-18ah-e-bike-li-ion-battery-hailong-mix-with-5-gold-plated-round-plug-replace-for-yose-power-13ah-hailong-battery

4. Q & A
Q1: Can I set max speed and voltage on display?
No. The max speed is defaulted to 25km/h. The voltage is defaulted to 36V. These settings are no need to changed. And the limit can't be canceled.

Q2: Can I change controller or display to increase max speed?
No. Other controllers or displays are not compatible with this kind of 250W rear motor kit.

Q3: Why I don't receive a controller? It is missing in parcel.
The kit has an integrated controller which is installed in battery holder already.
